Description

The Ruijie Reyee RG-EST350 V2 is a factory-paired wireless bridge kit built for long-distance point-to-point (PtP) connections in outdoor environments. Sold as a 2-unit pack, it’s designed for rural areas, scattered properties, and locations where fixed cabling isn’t practical, offering real-time data transmission across significant distances.

Operating on the 5 GHz band, the Ruijie Reyee RG-EST350 V2 delivers dual-stream Wi-Fi 5 (802.11ac Wave2) speeds of up to 867 Mbps, with 2×2 MU-MIMO ensuring stable, high-throughput performance for demanding outdoor bridging applications.

Range is where this kit truly shines. Equipped with 15 dBi directional beam antennas and a focused H: 31°, V: 14° coverage angle, the RG-EST350 V2 can easily transmit data from 5 km away in real time, making it a strong solution for connecting remote areas or extending network coverage across large open spaces.

Setup simplicity sets this bridge apart from typical long-range solutions. The units come factory-paired for long-distance installation, eliminating the need for complex manual alignment, so installers can achieve a stable link quickly even without specialized technical expertise.

Capacity is well suited for video surveillance deployments, supporting a maximum of 45 2MP cameras at 3 km distance or 20 2MP cameras at 5 km distance, making it a practical choice for extending CCTV coverage to remote or hard-to-cable locations.

Connectivity comes through 2 Gigabit Ethernet ports on each unit, giving installers reliable wired connections at both ends of the bridge link for switches, cameras, or other networked devices.

Built for the outdoors, the RG-EST350 V2 carries an IP54 weatherproof rating and operates reliably from -30°C to 65°C, along with 4kV lightning protection, ensuring stable performance across a wide range of environmental conditions.

Management is straightforward through WebUI, Ruijie Cloud, and the Ruijie Reyee App, giving administrators visually intuitive statistics monitoring and easy remote maintenance without needing to physically visit each site.

Power comes via 24V passive PoE at 9W, with the necessary PoE adapters included in the package, simplifying installation without requiring additional power infrastructure at remote sites.

Altogether, the Ruijie Reyee RG-EST350 V2 combines long-range Wi-Fi 5 performance, effortless factory-paired setup, and rugged IP54 durability, making it a smart, cost-effective choice for organizations needing dependable point-to-point wireless bridging over extended outdoor distances.

RG-EST350 V2 Hardware Specifications

RG-EST350 V2 Wi-Fi Radio

Specification	Details
Radio design	Single-radio2 spatial streams● Radio 1: 5 GHz, 2 spatial streams: 2 x 2, MIMO
5 GHz channel width	Auto/20/40/80 MHz

RG-EST350 V2 Antenna

Specification	Details
Antenna horizontal orientation	31°
Antenna vertical orientation	14°

RG-EST350 V2 Dimensions and Weight

Specification	Details
Product dimensions (W x D x H)	132 mm x 48 mm x 230 mm (5.20 in. x 1.89 in. x 9.06 in.) (excluding mounting bracket)

RG-EST350 V2 Power Supply and Consumption

Specification	Details
Number of PoE In ports	1

RG-EST350 V2 Environment and Reliability

Specification	Details
Operating temperature	–30°C to +65°C (–22°F to +149°F)
Operating humidity	5% RH to 95% RH (non-condensing)
MTBF	400,000 hours (about 45 years)
IP rating	IP54
