Description
The Ruijie Reyee RG-EST450G is a high-performance wireless bridge built for point-to-multipoint (PTMP) applications in demanding outdoor environments. With a wide 120° horizontal coverage angle, it’s ideal for streets, buildings, campuses, farms, and factories that need to connect multiple locations from a single central base station.
Operating on the 5 GHz band, the Ruijie Reyee RG-EST450G delivers wireless speeds of up to 867 Mbps on 5 GHz and 150 Mbps on 2.4 GHz, supporting Wi-Fi 5 (802.11ac) with 2×2 MIMO and 256-QAM modulation for higher throughput even at extended distances.
Range and coverage are defining strengths of this bridge. With a 15 dBi built-in antenna and H: 120°, V: 13° coverage angle, it delivers a working distance of up to 5 km, making it well suited for bridging remote locations, video surveillance deployments, and connections between multiple buildings.
Capacity is substantial for a PTMP base station, supporting up to 16 CPE devices from a single unit—ideal for connecting multiple remote sites or IP cameras back to one central access point without running extensive cabling.
Connectivity comes through 3 Gigabit Ethernet ports, giving installers flexibility for wired connections at both the base station and remote ends of the link, along with support for TDMA (Time Division Multiple Access) technology to reduce interference and improve link stability across multiple connections.
Setup is streamlined through One-Touch Pairing for PTMP mode, alongside support for Self-Organizing
RG-EST450G Hardware Specifications
RG-EST450G Wi-Fi Radio
| Specification | Details |
|---|---|
| Radio design | Dual-radio3 spatial streams● Radio 1: 2.4 GHz, 1 spatial stream: 1 x 1, SISO● Radio 2: 5 GHz, 2 spatial streams: 2 x 2, MIMO |
| 2.4 GHz channel width | Auto/20/40 MHz |
| 5 GHz channel width | Auto/20/40/80 MHz |
RG-EST450G Antenna
| Specification | Details |
|---|---|
| Antenna horizontal orientation | 120° |
| Antenna vertical orientation | 13° |
RG-EST450G Dimensions and Weight
| Specification | Details |
|---|---|
| Product dimensions (W x D x H) | 124 mm x 48 mm x 355 mm (4.88 in. x 1.89 in. x 13.98 in.) (excluding mounting bracket) |
RG-EST450G Power Supply and Consumption
| Specification | Details |
|---|---|
| Number of PoE In ports | 1 |
| Number of PoE/PoE+ In ports | 1 |
RG-EST450G Environment and Reliability
| Specification | Details |
|---|---|
| Operating temperature | –30°C to +65°C (–22°F to +149°F) |
| Operating humidity | 5% RH to 95% RH (non-condensing) |
| MTBF | 400,000 hours (about 45 years) |
| IP rating | IP55 |
RG-EST450G Software Specifications
RG-EST450G WLAN
| Specification | Details |
|---|---|
| Bridge speed test | Yes |
RG-EST450G Network Management and Monitoring
| Specification | Details |
|---|---|
| SON | Yes |
| AI heatmap | Yes |
| Restarting devices through Ruijie Reyee App | Yes |
| SNMPv1, v2c, and v3 | Yes |
RG-EST450G Applications
| Distance | Bridging Performance | RSSI | 3 MP Cameras | 4 to 5 MP Cameras | 6 to 7 MP Cameras | 7 to 8 MP Cameras |
|---|---|---|---|---|---|---|
| 1 km | 200 Mbps (HT40) | –59 dBm | 40 | 25 | 18 | 13 |
| 3 km | 130 Mbps (HT40) | –67 dBm | 30 | 18 | 10 | 8 |
| 5 km | 80 Mbps (HT40) | –73 dBm | 15 | 10 | 7 | 5 |
Note: The RSSI figures listed for RG-EST450G are specified when paired with the RG-EST350G CPE.
