Description

The Ruijie Reyee RG-RAP62 is a Wi-Fi 6 ceiling access point designed for businesses that want dependable gigabit wireless performance in a compact, stylish package. It’s a natural fit for hotels, restaurants, offices, and other small to medium-sized commercial spaces looking to modernize their network.

Built on dual-radio technology, the Ruijie Reyee RG-RAP62 operates across both 2.4 GHz and 5 GHz bands simultaneously. Supporting the Wi-Fi 6 (802.11ax) standard, it delivers a combined maximum throughput of up to 1774 Mbps—573 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz—keeping connections fast and stable.

MU-MIMO support on both bands allows the access point to serve multiple devices at once without the performance drops common in older hardware. This makes it well suited for busy environments where many users connect to the same network simultaneously, such as guest rooms or open office floors.

Capacity is another strong point. The access point supports up to 256 wireless users, with 64 on the 2.4 GHz band and 256 on the 5 GHz band, while managing up to 300 total devices. Effective coverage extends to roughly 125 square meters under ideal conditions, making it practical for medium-sized rooms and open layouts.

Deployment is simplified through Reyee Mesh, a self-organizing network (SON) technology supporting up to 300 access points. This allows administrators to expand wireless coverage across large properties without running additional cabling to every access point.

Intelligence is built into daily operation through AI Wireless Optimization (WIO 3.0), which automatically adjusts channel selection and transmit power to maintain consistent performance as network conditions change, reducing the need for manual tuning.

For standalone deployments, the Ruijie Reyee RG-RAP62 includes a built-in captive portal, enabling guest access management, bandwidth control, and secure authentication—all configurable through Ruijie Cloud or the Reyee mobile app without needing additional hardware.

Power flexibility rounds out the feature set, with support for PoE, PoE+, and a 12V DC adapter, giving installers multiple options depending on existing site infrastructure.

Design hasn’t been overlooked either. Its circular, compact form factor blends naturally into hotel and office interiors, making ceiling installation both easy and visually unobtrusive.

Altogether, the Ruijie Reyee RG-RAP62 delivers reliable Wi-Fi 6 speed, smart automation, and flexible management, making it a strong, budget-friendly choice for businesses upgrading their wireless infrastructure.

RG-RAP62 – Product Information

SpecificationDetails
Product Type	Ceiling AP

RG-RAP62 – Hardware Specifications

RG-RAP62 – Wi-Fi Radio

SpecificationDetails
Radio design	Dual-radio4 spatial streams● 2.4 GHz: 2 x 2, MU-MIMO● 5 GHz: 2 x 2, MU-MIMO
Maximum wireless data rate	1774 Mbps
6 GHz wireless data rate	No
5 GHz wireless data rate	1201 Mbps
2.4 GHz wireless data rate	573 Mbps

RG-RAP62 – Antenna

SpecificationDetails
Antenna	2.4 GHz: 2 built-in omnidirectional antennas5 GHz: 3 built-in omnidirectional antennas

RG-RAP62 – Dimensions and Weight

SpecificationDetails
Product dimensions (diameter x height)	Ø175mm x 39mm (Ø6.89 in. x 1.54 in.) (excluding the mounting bracket)
Color	White
Weight	≤ 0.4 kg (0.88 lbs) (without packaging materials)

RG-RAP62 – Port Specifications

SpecificationDetails
Number of 10/100/1000BASE-T ports	1

RG-RAP62 – Power Supply and Consumption

SpecificationDetails
Power supply	● DC power adapter● PoE/PoE+Note: If both the DC power adapter and PoE/PoE+ are available for power supply, the DC power adapter is preferred.
Local power supply	Yes, one DC power connector (12 V, 1.5 A)
Dimensions of the DC connector	Outer diameter: 5.5 mm (0.22 in.)Inner diameter: 2.1 mm (0.08 in.)Length: 10 mm (0.39 in.)
PoE budget	No
Maximum power consumption	12.95 W
