Description
Specifications
| Specification | Details |
|---|---|
| Interfaces | 8 × 10/100/1000 Mbps PoE+ RJ45 Ports (802.3af/at), 1 × 10/100/1000 Mbps RJ45 Port, 1 × Gigabit SFP/RJ45 Combo Port |
| Installation | Desktop, Wall Mount |
| Cooling | Fanless |
| Physical Security | Kensington Lock Support |
| Power Supply | AC/DC Adapter (Input: 100–240V AC, Output: 53.5V DC / 1.31A) |
| PoE Standard | IEEE 802.3af/at PoE+ |
| PoE Ports | 8 × PoE+ Ports |
| PoE Budget | 63 W Total, 30 W Max per Port |
| PoE Features | Fast PoE, Perpetual PoE, PoE Auto Recovery, Up to 250 m PoE Transmission |
| Switching Capacity | 20 Gbps |
| Packet Forwarding Rate | 14.88 Mpps |
| Packet Buffer Memory | 4 Mbit |
| MAC Address Table | 8K Entries |
| Jumbo Frame | 15 KB |
| Transmission Method | Store-and-Forward |
| QoS Features | Port-based, 802.1p, DSCP QoS, 8 Priority Queues, WRR, Bandwidth Control, Storm Control |
| Layer 2 Features | Static Link Aggregation (Up to 4 Groups), Port Isolation, Loopback Detection, 802.3x Flow Control, Port Mirroring, Port Statistics, LLDP, IEEE 802.3az EEE |
| Multicast | IGMP Snooping v1/v2/v3, Fast Leave, Report Suppression |
| VLAN Support | IEEE 802.1Q VLAN, Up to 32 VLAN Groups, 4K VLAN IDs |
| Management | Omada Cloud, Omada Hardware Controller, Omada Software Controller, Omada App, HTTPS/HTTP, DHCP Client, Cable Diagnostics, ONVIF, Auto Discovery, Batch Configuration & Firmware Upgrade |
| Surge Protection | ±6 kV |
| Dimensions (W × D × H) | 209 × 126 × 26 mm |
| Operating Temperature | -5°C to 40°C (23°F to 104°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Operating Humidity | 10%–90% RH (Non-condensing) |
| Storage Humidity | 5%–90% RH (Non-condensing) |
| Certifications | FCC, CE, RoHS |
