Description
Hardware Features
| Feature | Specification |
|---|---|
| Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x |
| Interface | 24× 10/100/1000Mbps RJ45 Ports (Auto Negotiation / Auto MDI/MDIX) |
| Network Media | 10BASE-T: UTP Category 3, 4, 5 Cable (Maximum 100m) 100BASE-TX/1000BASE-T: UTP Category 5, 5e or Above Cable (Maximum 100m) |
| Fan Quantity | Fanless |
| Physical Security Lock | No |
| Power Supply | 100-240VAC, 50/60Hz |
| Dimensions (W × D × H) | 11.6 × 7.1 × 1.7 in. (294 × 180 × 44 mm) |
| Mounting | Rack Mountable |
| Max. Power Consumption | 13.62W (220V/50Hz) |
| Max. Heat Dissipation | 46.44 BTU/h |
Performance
| Feature | Specification |
|---|---|
| Switching Capacity | 48Gbps |
| Packet Forwarding Rate | 35.7Mpps |
| MAC Address Table | 8K |
| Advanced Features | Isolation Mode: Ports 1–22 Loop Prevention: Ports 1–24 |
| Jumbo Frame | 10KB |
| Green Technology | Yes |
| Transmission Method | Store-and-Forward |
Others
| Feature | Specification |
|---|---|
| Certification | FCC, CE, RoHS |
| Package Content | 24-Port Gigabit Desktop/Rackmount Switch Power Cord Installation Guide Rackmount Kits Rubber Feet |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% Non-Condensing Storage Humidity: 5%~90% Non-Condensing |
