Name: Dahua NVR4216-EI 16CH WizSense NVR | Best price in Pakistan
SKU: DHI-NVR4216-EI
Price: 36500 PKR
Availability: InStock

Description

The Dahua NVR4216-EI is a 16-channel network video recorder that brings powerful WizSense AI capabilities to mid-sized surveillance systems, well suited to retail chains, offices, warehouses, and clinics running between roughly 8 and 16 cameras.

With a maximum decoding capability of 16 × 1080p at 30 fps and adaptive decoding support, the Dahua NVR4216-EI ensures smooth playback and effective management of high-definition streams. It supports advanced video compression technologies, including Smart H.265+, H.265, Smart H.264+, H.264, and MJPEG, allowing efficient storage without sacrificing video quality.

The recorder offers extensive compatibility by supporting connections with third-party network cameras, allowing for more flexible and scalable system designs, along with support for IP cameras with resolutions up to 16 MP for ultra-high-definition video.

Built-in AI functionalities on the Dahua NVR4216-EI include 1-channel face detection and recognition supporting up to 10 face databases and 20,000 face images, 2-channel perimeter protection, and 4-channel SMD Plus, which accurately filters human and vehicle targets from irrelevant motion to reduce false alarms.

When paired with compatible AI cameras, additional functionality extends to face detection and recognition, perimeter protection, SMD, people counting, stereo analysis, and heat mapping, giving businesses richer analytics even on cameras without built-in AI processing.

Storage capacity is generous for a device this size, with two SATA ports supporting up to 16 TB of storage, sitting comfortably within the range needed for month-long retention at typical channel resolutions, with room to archive footage onto cold storage as it ages out.

Video output flexibility is a strength of the Dahua NVR4216-EI, featuring dual output options with VGA up to 1920×1080 and HDMI up to 3840×2160 (4K), giving administrators flexibility in monitoring configurations depending on the displays available on-site.

Connectivity is rounded out with 1 RJ-45 10/100 Mbps Ethernet port, one front USB 2.0 port, and one rear USB 2.0 port, making it convenient to back up recordings or update the system firmware without added hardware.

Audio support includes G711A, G711U, PCM, and G726 compression formats, providing synchronized audio-video recording for a complete surveillance package, along with EPTZ support and one-click arming and disarming for straightforward system control.

The 1U rack chassis slots into any standard 19-inch cabinet and pairs cleanly with a separate PoE switch and UPS in a single half-height comms cabinet, since no PoE ports are built directly into the recorder.

With its 16-channel capacity, flexible AI analytics, and generous storage headroom, the Dahua NVR4216-EI is a strong choice for SMB surveillance deployments that need reliable, mid-density video management.

Dahua NVR4216-EI System

Main Processor

Industrial-grade processor

Operating System

Embedded Linux

Operating Interface

Web, Local GUI

Dahua NVR4216-EI AI

AI by Recorder

Face detection; face recognition; perimeter protection; and SMD

AI by Camera

Face detection; face recognition; perimeter protection; SMD; ANPR; people counting; stereo analysis; heat map

Dahua NVR4216-EI Perimeter Protection

Perimeter Performance AI by Recorder (Number of Channels)

2 channels, 10 IVS rules for each channel

Perimeter Performance of AI by Camera (Number of Channels)

All channels (8 targets/s)

Dahua NVR4216-EI Face Detection

Face Attributes

Gender; age group; glasses; expressions; face mask; beard

Face Detection Performance of AI by Recorder (Number of Channels)

1 channel (up to 12 face images/s each channel)

Face Detection Performance of AI by Camera (Number of Channels)

All channels (8 targets/s)

Dahua NVR4216-EI Face Recognition

Face Database Capacity

Up to 10 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.

Face Recognition Performance of AI by Recorder (Number of Channels)

8-channel FD (by camera) + FR (by recorder),image stream: 12 face images/s
1-channel FD (by recorder) + FR (by recorder), video stream: 12 face images/s

Face Recognition Performance of AI by Camera (Number of Channels)

All channels (8 targets/s)

Dahua NVR4216-EI SMD Plus

SMD Plus by Recorder

4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change

SMD by Camera

All channels (16 targets/s)

Dahua NVR4216-EI Audio and Video

Access Channel

16 channels

Network Bandwidth

AI disabled: 256 Mbps incoming, 256 Mbps recording and 256 Mbps outgoing
AI enabled: 180 Mbps incoming, 180 Mbps recording and 180 Mbps outgoing

Resolution

16 MP;12 MP;8 MP;6 MP;5 MP;4 MP;3 MP;1080p;720p;960p;D1;CIF

Decoding Capability

AI disabled: 2-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 4-channel 8 MP@30 fps; 4-channel 6 MP@30 fps; 6-channel 5 MP@30 fps; 8-channel 4 MP@30 fps; 16-channel 1080p@30 fps
AI enabled: 1-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 3-channel 8 MP@30 fps; 3-channel 6 MP@30 fps; 4-channel 5 MP@30 fps; 6-channel 4 MP@30 fps; 12-channel 1080p@30 fps; 16-channel 720p@30 fps

Video Output

1 HDMI, 1 VGA
HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
*Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable.

Multi-screen Display

1st Screen: 1/4/8/9/16
2nd Screen: 1/4/8/9/16

Third-party Camera Access

Panasonic, Sony, Hanwha, Axis, Pelco, Arecont, ONVIF, Canon

Dahua NVR4216-EI Compression Standard

Video Compression

Smart H.265+; H.265; Smart H.264+; H.264; MJPEG

Audio Compression

G.711a; G.711u; PCM; G726

Dahua NVR4216-EI Network

Network Protocol

HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UPnP; SNMP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera, DVR, NVS, etc.); P2P; Auto Registration

Mobile Phone Access

iOS; Android

Interoperability

ONVIF 23.12(Profile T; Profile S; Profile G); CGI; SDK

Browser

Chrome; IE9 and later; Firefox

Dahua NVR4216-EI Recording Playback

Multi-channel Playback

Up to 16 channels

Record Mode

General, motion detection; intelligent; alarm

Backup Method

USB device and network

Playback Mode

Instant playback, general playback, event playback, tag playback, smart playback

Storage

Disk Group

Yes

Dahua NVR4216-EI Alarm

General Alarm

Motion detection; privacy masking; video loss; scene changing; PIR alarm; IPC external alarm

Anomaly Alarm

Error (no disk; disk error; low space; low quota space; abnormal disk health; network disconnection; IP conflict; MAC conflict); video loss; video tampering; camera offline; audio detection

Intelligent Alarm

Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map

Alarm Linkage

Record; snapshot; IPC external alarm output; audio; buzzer; log; preset; email

Dahua NVR4216-EI Port

Audio Input

1-channel RCA

Audio Output

1-channel RCA

Alarm Input

4 channels

Alarm Output

2 channels

Disk Interface

2 SATA ports, up to 20 TB.The maximum HDD capacity varies with environment temperature.

USB

2 (1 front USB 2.0 port, 1 rear USB 2.0 port)

HDMI

VGA

Network Port

1 (10/100/1000 Mbps Ethernet port, RJ-45)

Dahua NVR4216-EI General

Power Supply

12 VDC, 4 A

Power Consumption

<10 W(without HDD)

Net Weight

1.51 kg (3.33 lb)

Gross Weight

2.76 kg (6.08 lb)

Product Dimensions

375 mm × 284.3 mm × 53 mm (14.76″ × 11.19″ × 2.09″) (W × D × H)

Packaging Dimensions

433 mm × 141 mm × 366 mm (17.05″ × 5.55″ × 14.41″) (W × L × H)

Operating Temperature

–10 °C to +55 °C (+14 °F to +131 °F)

Storage Temperature

–20 °C to +60 °C (–4 °F to +140 °F)

Operating Humidity

10%–93% (RH), non-condensing

Certifications

FCC: 47 CFR FCC Part15, SubpartB, Class A
CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014
CE-LVD: EN 62368-1:2014
