Description
The Dahua NVR4232-EI is a pro-class 32-channel network video recorder built on Dahua’s WizSense technology, suited for installs that have outgrown a single 16-channel unit but don’t yet justify dedicated rack-cabinet hardware — multi-floor offices, retail flagships, factory cells, and light-industrial yards.
Supporting Smart H.265+, H.265, Smart H.264+, and H.264 decoding formats, the Dahua NVR4232-EI delivers a maximum decoding capability of 16 × 1080p at 30 fps or 4 × 8MP at 30 fps, along with up to 256 Mbps of incoming, recording, and outgoing bandwidth, supporting IP cameras with resolutions up to 16 MP.
WizSense AI capabilities on the Dahua NVR4232-EI include 1-channel face detection and recognition, supporting up to 10 face databases and 20,000 face images, along with 2-channel perimeter protection featuring 10 IVS rules per channel, and 4-channel SMD Plus to reduce false alarms caused by irrelevant motion.
When paired with compatible AI cameras, additional functionality extends to face detection and recognition, perimeter protection across all channels (up to 8 targets/s), SMD Plus, ANPR, people counting, stereo analysis, and heat mapping, giving businesses richer analytics even beyond the recorder’s own onboard processing.
Storage capacity sits comfortably in the range needed for month-long retention at typical channel resolutions, with two SATA ports supporting up to 16 TB of storage, and room to archive footage onto cold storage as it ages out of active retention.
Video output flexibility rounds out the design, with 1 HDMI port supporting up to 4K (3840×2160) resolution and 1 VGA port for simultaneous local display, giving installers options depending on the monitors already in place at a given site.
Third-party network camera support is confirmed through ONVIF 22.06, CGI, and SDK interoperability, making the Dahua NVR4232-EI flexible enough to integrate with mixed-vendor surveillance systems rather than being locked into Dahua-only hardware.
The 1U rack chassis slots into any standard 19-inch cabinet and pairs cleanly with a separate PoE switch and UPS in a single half-height comms cabinet, since no PoE ports are built directly into the recorder — a preferred architecture on professional installs for finer VLAN control and larger PoE budgets.
Connectivity includes a single Gigabit Ethernet port, 2 USB 2.0 ports, and mobile phone access via iOS and Android apps, giving administrators remote monitoring flexibility from virtually anywhere.
With its 32-channel capacity, rich AI feature set, and flexible third-party camera support, the Dahua NVR4232-EI is a strong choice for growing mid-to-large surveillance deployments that need scalable, intelligent video management.
Dahua NVR4232-EI System
| Specification | Details |
|---|---|
| Main Processor | Industrial-grade processor |
| Operating System | Embedded Linux |
| Operating Interface | Web, Local GUI |
Dahua NVR4232-EI AI
| Specification | Details |
|---|---|
| AI by Recorder | SMD |
| AI by Camera | Face detection; face recognition; perimeter protection; SMD; people counting; stereo analysis; heat map |
Dahua NVR4232-EI Perimeter Protection
| Specification | Details |
|---|---|
| Perimeter Performance of AI by Camera (Number of Channels) | 6 channels |
Dahua NVR4232-EI Face Detection
| Specification | Details |
|---|---|
| Face Attributes | Gender; age group; glasses; expressions; face mask; beard |
| Face Detection Performance of AI by Camera (Number of Channels) | All channels (6 targets/s) |
Dahua NVR4232-EI Face Recognition
| Specification | Details |
|---|---|
| Face Recognition Performance of AI by Camera (Number of Channels) | All channels (6 targets/s) |
Dahua NVR4232-EI SMD Plus
| Specification | Details |
|---|---|
| SMD Plus by Recorder | 2 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
| SMD by Camera | All channels (12 targets/s) |
Audio and Video
| Specification | Details |
|---|---|
| Access Channel | 32 channels |
| Network Bandwidth | AI disabled: 160 Mbps incoming, 128 Mbps recording and 60 Mbps outgoingAI enabled: 80 Mbps incoming, 80 Mbps recording and 60 Mbps outgoing |
| Resolution | 12 MP;8 MP;6 MP;5 MP;4 MP;3 MP;1080p;720p;960p;D1;CIF;QCIF |
| Decoding Capability | AI disabled: 1-channel 12 MP@30 fps; 2-channel 8 MP@30 fps; 2-channel 6 MP@30 fps; 3-channel 5 MP@30 fps; 4-channel 4 MP@30 fps; 8-channel 1080p@30 fpsAI enabled: 1-channel 12 MP@30 fps; 1-channel 8 MP@30 fps; 2-channel 6 MP@30 fps; 2-channel 5 MP@30 fps; 3-channel 4 MP@30 fps; 7-channel 1080p@30 fps |
| Video Output | 1 HDMI, 1 VGASimultaneous:HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720VGA: 1920 × 1080, 1280 × 1024, 1280 × 720Heterogeneous:HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Multi-screen Display | AI disabled:Main Screen: 1/4/8/9/16/25/36, Sub Screen: 1/4/8/9/16AI enabled:Main Screen: 1/4/8/9/16, Sub Screen: 1/4/8/9/16 |
| Third-party Camera Access | ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha |
Compression Standard
| Specification | Details |
|---|---|
| Video Compression | Smart H.265+; H.265; Smart H.264+; H.264 |
| Audio Compression | G.711a; G.711u; PCM; G726 |
Dahua NVR4232-EI Network
| Specification | Details |
|---|---|
| Network Protocol | HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.) |
| Mobile Phone Access | iOS; Android |
| Interoperability | ONVIF 24.12 (Profile T; Profile S; Profile G); CGI; SDK |
| Browser | Chrome; IE; Safari; Edge; Firefox |
Recording Playback
| Specification | Details |
|---|---|
| Multi-channel Playback | Up to 16 channels |
| Record Mode | General, motion detection; intelligent; alarm |
| Backup Method | USB device and network |
| Playback Mode | Instant playback, general playback, event playback, tag playback, smart playback |
Dahua NVR4232-EI Storage
| Specification | Details |
|---|---|
| Disk Group | Yes |
Dahua NVR4232-EI Alarm
| Specification | Details |
|---|---|
| General Alarm | Motion detection; privacy masking; video loss; scene changing; PIR alarm; IPC external alarm |
| Anomaly Alarm | Error (no disk; disk error; low space; low quota space; network disconnection; IP conflict; MAC conflict); video loss; video tampering; camera offline; audio detection |
| Intelligent Alarm | Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map |
| Alarm Linkage | Record; snapshot; IPC external alarm output; audio; buzzer; log; preset; email |
Dahua NVR4232-EI Port
| Specification | Details |
|---|---|
| Audio Input | 1-channel RCA |
| Audio Output | 1-channel RCA |
| Alarm Input | 4 channels |
| Alarm Output | 2 channels (1-channel 12 V 1 A output） |
| Disk Interface | 2 SATA ports. Each disk can contain up to 20 TB. This limit varies depending on the environment temperature. |
| USB | 2 (1 front USB 2.0 port, 1 rear USB 2.0 port) |
| HDMI | 1 |
| VGA | 1 |
| Network Port | 1 (10/100/1000 Mbps Ethernet port, RJ-45) |
Dahua NVR4232-EI General
| Specification | Details |
|---|---|
| Power Supply | 12 VDC, 4 A |
| Power Consumption | Total output of NVR is <10 W(without HDD) |
| Net Weight | 1.49 kg (3.28 lb) |
| Gross Weight | 2.77 kg (6.11 lb) |
| Product Dimensions | 375.0 mm × 282.9 mm × 53.0 mm (14.76″ × 11.14″ × 2.09″) (W × D × H) |
| Packaging Dimensions | 433.0 mm × 141.0 mm × 366.0 mm (17.05″ × 5.55″ × 14.41″) (W × D × H) |
| Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Operating Humidity | 10%–93% (RH), non-condensing |
| Certifications | CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014 |
