Description
Camera
| Specification | Details |
|---|---|
| Image Sensor | 1/2.8″ CMOS |
| Pixel | 4 MP |
| Max. Resolution | 2560 (H) × 1440 (V) |
| ROM | 4 GB |
| RAM | 1 GB |
| Electronic Shutter Speed | 1/1 s–1/30000 s |
| Scanning System | Progressive |
| Min. Illumination | Color: 0.005 Lux@F1.6B/W: 0.0005 Lux@F1.60 Lux (IR light on) |
| Illumination Distance | 550 m (1804.46 ft) |
| Illuminator On/Off Control | Zoom Prio / Manual / SmartIR / Off |
| Illuminator Number | 2 IR lights, 1 Laser |
| Wiper | Support |
Lens
| Specification | Details |
|---|---|
| Focal Length | 3.95 mm–177.7 mm |
| Max. Aperture | F1.6–F4.9 |
| Field of View | H: 70.3°–1.8°V: 37°–1°D: 69.3°–2° |
| Optical Zoom | 45× |
| Focus Control | Auto / Semi-Auto / Manual |
| Close Focus Distance | 0.01 m–3 m (0.03 ft–9.84 ft) |
| Iris Control | Auto |
DORI Distance
| Specification | Distance |
|---|---|
| Detect | 3554 m (11660.10 ft) |
| Observe | 1421.6 m (4664.04 ft) |
| Recognize | 710.8 m (2332.02 ft) |
| Identify | 355.4 m (1166.01 ft) |
PTZ
| Specification | Details |
|---|---|
| Pan/Tilt Range | Pan: 0°–360° endlessTilt: –20°–+90°, auto flip 180° |
| Manual Control Speed | Pan: 0.1°–200°/sTilt: 0.1°–120°/s |
| Preset Speed | Pan: 240°/s; Tilt: 200°/s |
| Presets | 300 |
| Tour | 8 (up to 32 presets per tour) |
| Pattern | 5 |
| Scan | 5 |
| Power-off Memory | Support |
| Idle Motion | Preset / Tour / Pattern / Scanning |
| Protocol | DH-SD, Pelco-P/D (auto recognition) |
General Intelligence
| Specification | Details |
|---|---|
| Event Trigger | Motion detection, video tampering, scene changing, network disconnection, IP address conflict, illegal access, and storage anomaly |
| IVS | Object abandoned/missing |
Artificial Intelligence
| Specification | Details |
|---|---|
| Smart Capture | Support human, motor vehicle and non-motor vehicle image capture |
| Perimeter Protection | Tripwire and intrusion. Supports alarm triggering by target types (human and vehicle). Supports filtering false alarms caused by animals, rustling leaves, bright lights, etc. |
| Face Detection | Support |
| SMD PLUS | Support |
| Auto Tracking | Support |
Video
| Specification | Details |
|---|---|
| Compression | H.265; H.264B; H.264M; H.264H; MJPEG; MPEG4; H.265+; H.264+; MJPEG (sub stream) |
| Streaming Capability | 3 streams |
| Resolution | 4M (2560 × 1440); 3M (2048 × 1536); 1080P (1920 × 1080); 720P (1280 × 960); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) |
| Frame Rate | Main stream: 4M/3M (1–25/30 fps), 1080P/1.3M/720P (1–25/30 fps)Sub stream 1: D1/CIF (1–25/30 fps)Sub stream 2: 1080P (1–25/30 fps), 720P (1–25/30 fps) |
| Bit Rate Control | Variable / Constant |
| Bit Rate | Main stream (default resolution)H.264: 3 Kbps–20480 KbpsH.265: 3 Kbps–20480 Kbps |
| Day/Night | Auto (ICR) / Color / B/W |
| BLC | Support |
| WDR | 120 dB |
| HLC | Support |
| White Balance | Auto / Indoor / Outdoor / Tracking / Manual / Sodium lamp / Natural light / Street lamp |
| Gain Control | Auto / Manual |
| Noise Reduction | 2D / 3D |
| Motion Detection | Support |
| Region of Interest (RoI) | Support |
| Image Stabilization | Electronic |
| Defog | Digital |
| Digital Zoom | 16× |
| Flip | 180° |
| Privacy Masking | Up to 24 areas, and up to 8 areas in the same view |
Audio
| Specification | Details |
|---|---|
| Compression | G.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G.722.1; G.729; G.723 |
Network
| Specification | Details |
|---|---|
| Ethernet | RJ-45 (10/100Base-T) |
| Protocol | IPv4; IPv6; HTTP; HTTPS; 802.1x; QoS; FTP; SMTP; UPnP; SNMPv1/v2c/v3 (MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP |
| Interoperability | ONVIF Profile S&G&T; CGI |
| Streaming Method | Unicast / Multicast |
| User/Host | 19 |
| Storage | FTP; Micro SD card (256 G); P2P |
| Browser | IE7 and later versionsChrome 42 and earlier versionsFirefox 52 and earlier versionsSafari |
| Management Software | Smart PSS; DSS; DMSS; Easy4ip; IVSS |
| Mobile Phone | iOS; Android |
Certification
| Specification | Details |
|---|---|
| Certifications | CE: EN62368-1; EN55032; EN61000-3-2; EN61000-3-3; EN55024; EN55035; EN50130-4FCC: 47 CFR FCC Part15, Subpart B, Class A; ANSI C63.4: 2014 |
Port
| Specification | Details |
|---|---|
| RS-485 | 1 (Baud rate range: 1200 bps–115200 bps) |
| Audio Input | 1 |
| Audio Output | 1 |
| Alarm I/O | 7/2 |
Power
| Specification | Details |
|---|---|
| Power Supply | DC36V/2.23A; HI-PoE |
| Power Consumption | Basic: 20 WMax.: 36 W (IR light and PTZ on at minimum voltage) |
Environment
| Specification | Details |
|---|---|
| Operating Temperature | –40°C to 70°C (–40°F to 158°F) |
| Operating Humidity | ≤95% |
| Protection | IP67; TVS 8000V lightning proof; Surge protection |
Structure
| Specification | Details |
|---|---|
| Casing | Metal |
| Dimensions | 382 mm × Φ240 mm (15.04″ × Φ9.45″) |
| Net Weight | 6.8 kg (14.99 lb) |
| Gross Weight | 9.2 kg (20.28 lb) |
