Description

RG-ES126FGS-P is a 24-port unmanaged Fast Ethernet PoE switch built for small and medium-sized businesses that need simple, dependable connectivity for surveillance and general networking devices. Made by Ruijie, this switch is well suited for intelligent community networks, small offices, and CCTV installations that need reliable plug-and-play performance.

At the core of RG-ES126FGS-P is 24 x 10/100BASE-T PoE+ ports, along with 2 x 10/100/1000BASE-T ports and 1 GE combo port, giving businesses genuine flexibility for both PoE device access and Gigabit uplink connectivity through fiber or copper.

Power delivery is where RG-ES126FGS-P truly stands out. The switch offers a substantial 370W PoE budget, and being compliant with IEEE 802.3at while remaining backward compatible with IEEE 802.3af, all 24 Fast Ethernet ports support PoE power supply, automatically identifying compliant powered devices and supplying power directly through Ethernet cables.

Flexibility is a genuine strength as well. RG-ES126FGS-P works in extend mode, default mode, or isolation mode, letting installers switch the working mode simply by toggling the DIP switch on the front panel, adapting the switch to different networking requirements without complex configuration.

Being unmanaged doesn’t mean invisible, either. RG-ES126FGS-P remains visible on Ruijie Cloud, giving administrators basic remote insight into the device even without full managed switch configuration, supporting an intelligent and secure CCTV network setup.

Reliability is built directly into the hardware too. RG-ES126FGS-P includes surge protection up to 4kV, along with fan speed control for consistent cooling, and all ports offer line rate forwarding performance for greater network flexibility and consistent throughput.

Ease of use rounds out the package nicely. As a genuinely plug-and-play switch, RG-ES126FGS-P lets small and medium-sized enterprises expand their home or office networks without being limited by existing electrical wiring, simplifying rollout for growing surveillance and data networks alike.

Physical installation is straightforward as well. RG-ES126FGS-P can be installed in a standard 19-inch EIA rack using the included mounting accessories, making it easy to integrate into existing equipment racks or server rooms.

Whether deployed for a small office or a CCTV-focused surveillance network, RG-ES126FGS-P delivers dependable 24-port PoE connectivity, flexible working modes, and a substantial 370W power budget in one unmanaged switch.

Full technical specifications are listed below.

RG-ES126FGS-P PRODUCT INFORMATION

Feature	Specification
Product Category	Layer 2
Warranty	3 years
Device Model	RG-ES126FGS-P

RG-ES126FGS-P PORT SPECIFICATIONS

Feature	Specification
Total number of RJ45 ports	26
Number of 10/100BASE-T ports	24
Number of 10/100/1000BASE-T ports	2
Total number of optical ports	1
Number of 1GE combo ports	1
Number of 1GE SFP ports	1

RG-ES126FGS-P POWER SUPPLY AND CONSUMPTION

Feature	Specification
Number of PoE Out ports	24
Number of PoE/PoE+ Out ports	24
PoE budget	370 W
PoE power pins	1–2 (+), 3–6 (-)
PoE watchdog	Yes
