Description

RG-ES216GC2MS is an 18-port Layer 2 smart cloud managed non-PoE switch built for business and CCTV networks that need dense Gigabit access paired with high-speed fiber uplinks. Made by Ruijie, this switch is well suited for offices, surveillance deployments, and growing networks that already power their connected devices separately.

At the core of RG-ES216GC2MS is 16 Gigabit Ethernet ports paired with two 2.5 Gigabit SFP ports, providing fast, reliable connectivity for computers, cameras, access points, and other network devices, while the SFP uplinks help reduce bottlenecks as the network expands.

Network resilience is where RG-ES216GC2MS truly stands out. The switch supports ERPS network redundancy, which helps maintain service continuity by providing rapid recovery if a network link fails, along with static link aggregation, VLAN support, and AI-powered failover for improved network performance and reliability.

Surveillance-focused features add real value too. Like other switches in Ruijie’s smart surveillance lineup, RG-ES216GC2MS supports convenient and flexible VLAN division, automatically separating different VLANs according to the type of equipment connected to each port, so the surveillance network and data network don’t interfere with each other.

Ease of use is a genuine strength as well. Under factory default state, RG-ES216GC2MS requires zero configuration after being plugged in, letting the video surveillance network be set up quickly once cameras and a DVR are correctly connected.

Reliability is built directly into the hardware too. The switch’s ports offer surge protection of up to 6kV, reducing the probability of port damage from electrical surges, and the switch also supports network cables made of non-standard materials for added installation flexibility.

Management is genuinely convenient too. Lifetime-free Ruijie Cloud and Reyee App management enable remote configuration, monitoring, and maintenance, along with VLANs, port isolation, cable testing, and traffic controls that improve network organisation, security, and troubleshooting, all from a smartphone or browser.

Whether deployed for a growing office or a CCTV-heavy surveillance network, RG-ES216GC2MS delivers extensive 16-port Gigabit connectivity, high-speed 2.5G fiber uplinks, and dependable cloud management in one cost-effective non-PoE switch.

Full technical specifications are listed below.

RG-ES216GC2MS PRODUCT INFORMATION

Feature	Specification
Product Category	Layer 2
Warranty	3 years
Device Model	RG-ES216GC2MS

RG-ES216GC2MS PORT SPECIFICATIONS

Feature	Specification
Total number of RJ45 ports	16
Number of 10/100/1000BASE-T ports	16
Total number of optical ports	2
Number of 2.5GE SFP ports	2
PoE Support	Non-PoE
