Description

The Ruijie Reyee RG-RAP6260(H)-D is a high-density outdoor directional access point built for long-range, point-focused Wi-Fi 6 coverage. Its directional antenna design makes it well suited for stadiums, plazas, streets, and other outdoor environments where signal needs to be aimed at a specific coverage zone rather than spread omnidirectionally.

Combining a revolutionary mix of OFDMA and 1024QAM, the latest 802.11ax standard, 160 MHz band support, and dual-band 4×4 MU-MIMO, the Ruijie Reyee RG-RAP6260(H)-D reaches a wireless aggregation rate of up to 5.95 Gbps—with 1148 Mbps on 2.4GHz and 4804 Mbps on 5GHz—placing it among the fastest outdoor access points in the Reyee lineup.

Directional coverage is the defining feature of this model. Equipped with 8 built-in directional antennas offering 10 dBi gain on 2.4GHz and 9 dBi gain on 5GHz, it delivers focused, long-range signal strength ideal for narrow corridors, streets, or specific outdoor zones that need concentrated coverage.

Connectivity is future-ready through a 2.5GbE port alongside a 1G SFP port ideal for fiber optics. With the gigabit SFP port, the device supports up to 20 km of transmission from a data center using single-mode fiber, making it a strong fit for large campuses and long-distance deployments.

Built for the harshest outdoor conditions, the device is completely sealed, waterproof, dustproof, moisture-proof, and flame-retardant, with an IP68 rating. It also includes wind erosion protection, a wide operating temperature range, and 4 kV surge protection, including protection on the DC port.

Client capacity is substantial, supporting up to 512 users, making it well suited for high-density outdoor gatherings, events, or busy public spaces where large numbers of devices connect simultaneously.

Power flexibility is built in as well, with support for both a DC power adapter and PoE+/PoE++, giving installers options based on existing site infrastructure (the DC power adapter is preferred when both are available).

Deployment simplicity comes through Reyee Mesh technology, allowing additional outdoor access points to be added easily as coverage needs expand across a property.

Altogether, the Ruijie Reyee RG-RAP6260(H)-D combines ultra-fast Wi-Fi 6 speed, focused directional coverage, and rugged IP68 durability, making it a smart choice for organizations needing dependable, high-capacity outdoor wireless coverage in targeted zones.

RG-RAP6260(H)-D Product Information

Product Type	Outdoor AP

RG-RAP6260(H)-D Hardware Specifications

RG-RAP6260(H)-D Wi-Fi Radio

Radio design	Dual-radio8 spatial streams● 2.4 GHz: 4 x 4, MU-MIMO● 5 GHz: 4 x 4, MU-MIMO
Maximum wireless data rate	5950 Mbps
6 GHz wireless data rate	No
5 GHz wireless data rate	4803 Mbps
2.4 GHz wireless data rate	1147 Mbps

RG-RAP6260(H)-D Antenna

Antenna	2.4 GHz: 4 built-in directional antennas5 GHz: 4 built-in directional antennas

RG-RAP6260(H)-D Dimensions and Weight

Product dimensions (W x D x H)	300 mm x 300 mm x 75.5 mm (11.81 in. x 11.81 in. x 2.97 in.) (excluding the mounting bracket)
Color	White
Weight	≤ 3.5 kg (7.72 lbs.) (without packaging materials)

RG-RAP6260(H)-D Port Specifications

Number of 10/100/1000/2500BASE-T ports	1
Number of 1GE SFP ports	1

RG-RAP6260(H)-D Power Supply and Consumption

Power supply	● DC power adapter● PoE+/PoE++Note: If both the DC power adapter and PoE+/PoE++ are available for power supply, the DC power adapter is preferred.
Local power supply	Yes, one DC power connector (48 V, 1 A)
Dimensions of the DC connector	Outer diameter: 5.5 mm (0.22 in.)Inner diameter: 2.1 mm (0.08 in.)Depth: 10 mm (0.39 in.)
PoE budget	No
Maximum power consumption	40 W
