Description
The TP-Link Tapo D130 is a smart wired video doorbell built to give homeowners a clear, wide view of their entryway, powered directly through existing doorbell wiring. As the first wired doorbell in the Tapo lineup, it combines sharp video, color night vision, and AI detection in a reliable, always-powered package.
Delivering 2K 5MP live view at 2560 x 1920 resolution, the TP-Link Tapo D130 lets homeowners always know what’s happening at their door through the Tapo app, with a starlight sensor capturing fine details even in low-light environments before night fully sets in.
Field of view is genuinely impressive, with an ultra-wide 180° diagonal FOV (172° horizontal, 144° vertical) and 4:3 aspect ratio delivering head-to-toe views even when a person stands as close as 0.4m—distances at which many other video doorbells lose important detail.
Night vision is a standout feature too. With an embedded spotlight and 850nm IR LED offering up to 25 feet of range, the Tapo D130 reveals high-fidelity details and vivid color at night, going well beyond the grainy black-and-white footage typical of many doorbell cameras.
Placement flexibility is well thought out, with included 5° vertical and 15° horizontal mounting wedges letting homeowners adjust the doorbell’s view angle without reducing its overall field of view—useful for getting a complete picture of packages left on the ground.
Smart AI detection adds real value to daily use, with algorithms that identify people and cars and notify users as needed, helping cut down on the irrelevant alerts common with basic motion-only doorbells.
Communication is handled through multiple ways to answer, including two-way audio or a recorded quick response, letting homeowners speak directly with visitors or delivery drivers through the Tapo app from anywhere.
Storage flexibility rounds out the package, with recorded video saved either to an installed microSD card (up to 512GB, sold separately) or through Tapo Care cloud storage service (subscribed separately), giving users a choice between local and cloud-based backup.
Built for the outdoors, the Tapo D130 carries an IP65 rating for water and dust resistance, runs on existing doorbell wiring (8-24V AC), and works seamlessly with Amazon Alexa and Google Assistant for added smart home integration.
Altogether, the TP-Link Tapo D130 combines sharp 2K video, genuine color night vision, and a dependable hard-wired connection, making it a smart, reliable choice for homeowners wanting always-on video doorbell security at their front door.
Tapo D130 Camera Specifications
| Feature | Details |
| Image Sensor | 1/2.7“ Progressive Scan CMOS Sensor |
| Lens |
Focal Length: 1.18 mm
Aperture: F1.8
Field of View: 180° (Diagonal), 172° (Horizontal), 144° (Vertical)
|
| Night Vision | 850 nm IR LED (30 ft / 10 m) |
| Lighting | Built-in Spotlights |
| Interface & Buttons |
1× RESET Button
1× Doorbell Button
|
Tapo D130 Hub / Chime Specifications
| Feature | Details |
| Interface & Buttons |
1× RESET Button
1× MicroSD Card Slot (Up to 512 GB)
1× RING Button
|
Tapo D130 Video & Audio Specifications
| Feature | Details |
| Maximum Resolution | 2K 5MP (2560 × 1920 px) |
| Frame Rate | 15 / 20 / 25 / 30 fps (Default: 15 fps) |
| Digital Zoom | 16x |
| Video Compression | H.264 |
| Live View | Yes |
| Image Enhancement | 3DNR, WDR |
| Audio Input & Output | Built-in Microphone and Speaker |
| Audio Communication | Two-Way Audio with Noise Cancellation |
Tapo D130 Storage Specifications
| Feature | Details |
| Local Storage | MicroSD Card Slot on Camera (Up to 512 GB) |
| Cloud Storage | Tapo Care Cloud Storage Services (Subscription required) |
Tapo D130 Detection & Notification Specifications
| Feature | Details |
| AI Detection | Motion Detection, Line-Crossing Detection, Tamper Detection, Person Detection, Pet Detection, Vehicle Detection, Package Detection |
| Activity Zones | Yes (*Only works with Motion Detection) |
| Output Notification | System Notification, System Notification with Snapshot (Tapo Care Services) |
Tapo D130 Network & Security Specifications
| Feature | Details |
| Network Connectivity | Connect via Wi-Fi |
| Wireless Connectivity | IEEE 802.11b/g/n, 2.4 GHz Wi-Fi |
| RTSP Support | Yes |
| Security |
On-Device Machine Learning
128-bit AES Encryption with SSL/TLS
WPA/WPA2-PSK/WPA3
|
Tapo D130 Power Specifications
| Feature | Details |
| Power Source | Hardwired Only |
| Input Voltage | Hardwired: 8–24 VAC, 10 VA min |
Tapo D130 Physical & Environmental Specifications
| Feature | Details |
| Doorbell Dimensions (W × D × H) | 3.35 × 1.67 × 1.28 in (85 × 42.5 × 32.5 mm) |
| Chime Dimensions (W × D × H) | 2.87 × 1.71 × 1.85 in (73 × 43.5 × 46.9 mm) |
| Weather Resistance | IP65 |
| Operating Temperature | -20°C to 45°C |
| Storage Temperature | -20°C to 60°C |
| Operating Humidity | 10% to 90% RH, Non-condensing |
| Storage Humidity | 5% to 90% RH, Non-condensing |
| Mounting Options | Stick to a Wall, Mount to a Wall |
Tapo D130 General & Compatibility Specifications
| Feature | Details |
| Smart Integration | Google Assistant, Amazon Alexa |
| System Requirements | Tapo App: iOS 9.0 or higher, Android 4.4 or higher |
| Package Contents |
Tapo D130 Video Doorbell Wired
Tapo Doorbell Chime
Mounting Bracket
Horizontal Mounting Wedge
Vertical Mounting Wedge
Mounting Template
3M Adhesive
Foam Pad
Extension Wires
Jumpers for Existing Chime
Mounting Screws
Mounting Anchors
Mounting Wedge Screws
Doorbell Detaching Pin
Wire Nuts
Quick Start Guide
|
| Certifications | CE, RoHS, FCC, EAC, UKCA, KC, ETL, IC, IP65 |
