Description
For outdoor and industrial sites that need wireless signal to travel far in one focused direction, the TP-Link EAP650 D30-Outdoor is designed to deliver exactly that. Built as part of TP-Link’s directional Omada access point lineup, it trades wide-angle coverage for long, narrow-beam range.
The defining feature of the TP-Link EAP650 D30-Outdoor is its 30-degree high-gain directional antenna array. Compared to wider-beam siblings, this narrower angle concentrates signal strength into a tighter path, making it ideal for long aisles, perimeter fencing, narrow outdoor corridors, loading lanes, and elongated warehouse zones where distance matters more than spread.
Performance stays firmly in Wi-Fi 6 territory. The TP-Link EAP650 D30-Outdoor delivers up to 2402 Mbps on the 5 GHz band and 574 Mbps on 2.4 GHz, giving it enough combined throughput to support scanners, tablets, AGVs, and IoT devices operating simultaneously along a focused coverage path.
Ruggedness is central to its design. The TP-Link EAP650 D30-Outdoor uses a fully sealed IP68 enclosure, protecting it from dust ingress and water submersion, while its -30°C to +70°C operating range lets it function reliably in unheated storage facilities, exposed outdoor installations, or extreme seasonal climates.
Mobility features round out the package. With 802.11k/v/r seamless roaming, handheld scanners and automated guided vehicles can move along a facility without losing connection, switching automatically between access points as signal strength shifts — a must-have for logistics and fulfillment operations.
Installation is kept practical through 802.3at PoE support, allowing data and power to run over a single cable even at remote or outdoor mounting points. Combined with Omada Mesh technology, multiple units can be deployed along a perimeter or corridor to extend directional coverage in a continuous chain rather than relying on a single access point.
Management is centralized through TP-Link’s Omada SDN platform, giving administrators control over access points, switches, and gateways from one interface — accessible via the Omada app or web UI, whether managed locally or from the cloud.
In short, the TP-Link EAP650 D30-Outdoor is purpose-built for scenarios where standard omnidirectional coverage falls short — long warehouse rows, fence lines, narrow yards, and stretched outdoor paths — pairing focused-range performance with industrial-grade durability and centralized manageability.
TP-Link EAP650 D30-Outdoor HARDWARE FEATURES |
|
|---|---|
| Interface | 1× Gigabit Ethernet Port (supports 802.3at PoE or 48V Passive PoE) |
| Button | Reset |
| Power Supply | • 802.3at PoE • 48V Passive PoE |
| Max. Power Consumption | • EU: 12.5W (802.3at PoE or Passive PoE) • US: 14.7W (802.3at PoE or Passive PoE) |
| Dimensions ( W x D x H ) | 8.2 × 2.3 × 9.1 in (207.5 × 58 × 230 mm) |
| Antenna | Built-in Directional Antennas: • 2.4 GHz: 2× 12 dBi • 5 GHz: 2× 15 dBi Beamwidth: 30° Horizontal; 30° Vertical |
| Bluetooth | Yes |
| Weatherproof Enclosure | IP68 |
| Mounting | Wall/Pole/Ceiling Mount |
TP-Link EAP650 D30-Outdoor WIRELESS FEATURES |
|
|---|---|
| Concurrent Clients | 250+** |
| Wireless Standards | IEEE 802.11 a/b/g/n/ac/ax |
| Frequency | 2.4 GHz, 5 GHz |
| Signal Rate | 574 Mbps (2.4 GHz) + 2402 Mbps (5 GHz)† |
| Wireless Functions | • 1024-QAM • DL/UL OFDMA • Multiple SSIDs (Up to 16 SSIDs, 8 on each band) • Enable/Disable Wireless Radio • Enable/Disable SSID Broadcast • Guest Network • Automatic Channel Assignment • Transmit Power Control (Adjust Transmit Power on dBm) • QoS (WMM) • 2 × 2 (2.4 GHz & 5 GHz) DL/UL MU-MIMO • Omada Mesh§ • Seamless Roaming(802.11k/v/r)§ • Band Steering • Load Balance • Airtime Fairness • Beamforming • RADIUS Accounting • MAC Authentication • Reboot Schedule • Wireless Schedule • Wireless Statistics • Static IP/Dynamic IP |
| Wireless Security | • Captive Portal Authentication§ • Access Control • Wireless Mac Address Filtering • Wireless Isolation Between Clients • SSID to VLAN Mapping • Rogue AP Detection • 802.1X Support • WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| Transmission Power | • EU: < 20 dBm (2.4GHz, EIRP); < 23dBm (5 GHz, band1 & band 2, EIRP);< 30 dBm (5 GHz,band 3, EIRP); • US: < 30 dBm (2.4 GHz); < 30 dBm (5 GHz) |
TP-Link EAP650 D30-Outdoor Management Features |
|
|---|---|
| Omada App | Yes |
| Restore & Backup | Yes |
| NTP | Yes |
| Centralized Management | • Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller |
| Cloud Access | Yes. Require the use of an Omada controller. |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1, v2c, v3 |
| System Logging Local/Remote Syslog | Yes |
| SSH | Yes |
| Web-based Management | Yes |
| Multi-site Management | Yes |
| Zero-Touch Provisioning | Yes. Requiring the use of Omada Cloud-Based Controller |
OTHERS |
|
|---|---|
| Certification | CE, FCC, RoHS |
| Package Content | • Access Point EAP650 D30-Outdoor • Mounting Kits • Installation Guide • Waterproof Kit |
| System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
| Environment | • Operating Temperature: -30–70 ℃ (-22–158 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
