Description
Ideal for both small offices and homes, the TP-Link TL-SG108S-M2 8-Port 2.5G Unmanaged Network Switch offers high-speed connectivity that enhances 4K video streaming, file transfers, and even gaming LAN parties.
With eight 2.5G Ethernet ports, the TP-Link TL-SG108S-M2 Switch allows users to connect a variety of compatible devices including computers, servers, NAS drives, and access points. Supporting a 40 Gb/s switching capacity and 29.8 Mpps forwarding rate, this unmanaged switch provides smooth data transfers.
As the flagship 2.5G product, the TP-Link TL-SG108S-M2 offers an easy upgrade to a super-fast network without the need to upgrade to Cat6 wiring. Instantly upgrading to 2.5 Gbps reduces wiring costs and hassle for homes and small offices alike.
Auto-negotiation intelligently senses link speeds and adjusts between 3 speeds (100Mb/1G/2.5G) for compatibility and optimal performance across all connected devices, including 2.5G NAS, 2.5G PCIe adapters, gaming consoles, VR gaming, and 2.5G WiFi 6 access points.
The switch can also be configured to prioritize video game traffic to help eliminate latency during LAN parties, with 802.1p/DSCP QoS keeping gaming, streaming, and everyday traffic running smoothly across the network.
IEEE 802.3x flow control is incorporated for stable data transfer, alleviating traffic congestion and ensuring reliable connections even when multiple high-bandwidth devices are active at the same time.
The TP-Link TL-SG108S-M2‘s durable metal case allows for efficient heat dissipation, excellent signal interference prevention, and a long service life, giving it the durability needed for continuous operation in busy home and office environments.
Its fanless design reduces power consumption and noise generated, making it ideal for noise-sensitive environments, whether tucked behind a TV or mounted in a quiet home office.
Setup is refreshingly simple, as the switch offers plug-and-play functionality, requiring no software installation or configuration, meaning it can be up and running within minutes of being connected.
Users can place the TP-Link TL-SG108S-M2 on a desk or mount it to the wall according to their demand, giving it the flexibility to fit into a variety of home and small office layouts without added complexity.
With eight full 2.5G ports and LED indicators showing power status, connection speed, and data transmission activity, administrators can quickly monitor the switch’s status without needing a dedicated management interface.
With its 2.5G speeds, hassle-free cabling compatibility, and silent fanless operation, the TP-Link TL-SG108S-M2 offers a dependable, cost-effective way to bring multi-gigabit connectivity to homes, offices, and gaming setups alike.
TP-Link TL-SG108S-M2 Hardware Features
| Feature | Specification |
|---|---|
| Standards and Protocols | IEEE 802.3u, 802.3ab, 802.3x, 802.1p, 802.3bz |
| Interface | 8× 100Mbps / 1Gbps / 2.5Gbps Ports, Auto-Negotiation, Auto-MDI/MDIX |
| Fan Quantity | Fanless |
| External Power Supply | External Power Adapter (Output: 12VDC / 1.0A) |
| LED | Power Link/Act Indicators |
| Dimensions (W × D × H) | 6.2 × 4.0 × 1.0 in (158 × 101 × 25.4 mm) |
| Max. Power Consumption | 8.87W |
| Max. Heat Dissipation | 30.158 BTU/h |
TP-Link TL-SG108S-M2 Performance
| Feature | Specification |
|---|---|
| Switching Capacity | 40Gbps |
| Packet Forwarding Rate | 29.8Mpps |
| MAC Address Table | 4K |
| Jumbo Frame | 12KB |
TP-Link TL-SG108S-M2 Software Features
| Feature | Specification |
|---|---|
| Advanced Features | 802.3X Flow Control 802.1p/DSCP QoS IGMP Snooping |
| Transmission Method | Store and Forward |
Others
| Feature | Specification |
|---|---|
| Certification | CE, FCC, RoHS |
| Package Content | 8-Port 2.5G Multi-Gigabit Desktop Switch TL-SG108S-M2 Power Adapter Installation Guide Rubber Feet |
| Environment | Operating Temperature: 0–40°C (32–104°F) Storage Temperature: -40–70°C (-40–158°F) Operating Humidity: 10–90% RH Non-Condensing Storage Humidity: 5–90% RH Non-Condensing |
