Description

Overview
Dimensions ⌀220 x 48.1 mm (⌀8.7 x 1.9″)
WiFi Standard WiFi 5
Spatial Streams 8
Coverage Area 140 m² (1,500 ft²)
Max. Client Count 500+
Uplink GbE
Mounting Ceiling, Wall (Pro Mount Included)
Power Method PoE+

Performance
MIMO
5 GHz 4 x 4 (DL MU-MIMO)
2.4 GHz 4 x 4 (DL MU-MIMO)
Max. Data Rate
5 GHz 1.7 Gbps (BW80)
2.4 GHz 800 Mbps (BW40)
Antenna Gain
5 GHz 4 dBi
2.4 GHz 3 dBi
Max. TX Power
5 GHz 25 dBm
2.4 GHz 25 dBm
Max. BSSIDs 8 per Radio
Supported Data Rates
802.11ac (WiFi 5)
6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80)
802.11n
6.5 Mbps to 450 Mbps (MCS0 – MCS23, HT 20/40)

Features
Wireless Meshing ✓
Band Steering ✓
802.11v BSS Transition Management ✓
802.11r Fast Roaming ✓
802.11k Radio Resource Management (RRM) ✓
Advanced Radio Management ✓
Passpoint (Hotspot 2.0) ✓
Captive Hotspot Portal
Custom Branding Landing Page ✓
Voucher Authentication ✓
Payment-Based Authentication ✓
External Portal Server Support ✓
Password Authentication ✓
Guest Network Isolation ✓
Private Pre-Shared Key (PPSK) ✓
WiFi Speed Limiting ✓
Client Device Isolation ✓
WiFi Schedules ✓
RADIUS over TLS (RadSec) ✓
Dynamic RADIUS-assigned VLAN ✓

Hardware
Max. Power Consumption 17W
Includes PoE Adapter ✓
Supported Voltage Range 44–57V DC
Networking Interface (2) GbE RJ45 ports
Weight Device: 700 g (1.5 lb)
With mount: 830 g (1.8 lb)
Management Ethernet
WiFi LEDs
System
Status
Channel Bandwidth HT 20/40, VHT 20/40/80 (MHz)
NDAA Compliant ✓
Certifications
CE, FCC, IC, Anatel
Operating Frequency
US/CA:
2400 – 2472 MHz
U-NII-1: 5150 – 5250 MHz
U-NII-2A: 5250 – 5350 MHz
U-NII-2C: 5470 – 5725 MHz
U-NII-3: 5725 – 5850 MHz

Worldwide:
2400 – 2483.5 MHz
5150 – 5850 MHz
Ambient Operating Temperature -10 to 70° C (14 to 158° F)
Ambient Operating Humidity 5 to 95% noncondensing

Software
Application Requirements
UniFi Network
Version 6.0.45 and later
