Description
The HSGQ-XE08R 8 Port EPON OLT is a compact 1U cassette-style Optical Line Terminal designed for modern FTTH, FTTB, and FTTx network deployments that need more capacity than a 4-port unit. It provides 8 downlink EPON ports along with 4 Gigabit Ethernet RJ45 ports and 4 10G SFP+ uplink ports, giving ISPs and system integrators the flexibility to configure electrical and optical connections according to their network design.
Each EPON port on the HSGQ-XE08R 8 Port EPON OLT supports a 1:64 split ratio, allowing the device to serve up to 512 ONUs under full configuration — a strong fit for operator access and enterprise park networks covering a larger subscriber footprint. Backed by 512MB DDR memory and 32MB Flash, the unit is built to handle high-speed data transmission without slowing down as the network scales.
Built to follow the IEEE 802.3ah EPON standard, the HSGQ-XE08R 8 Port EPON OLT supports multiple management methods, including CLI, Web, and SNMP, along with advanced Layer 2 features like VLAN, QinQ, QoS, ACL, and link aggregation to keep larger networks organized and secure. Below are the full technical specifications.
HSGQ-XE08R 8 Port Epon OLT Specifications
| Specification | Details |
|---|---|
| Model | HSGQ-XE08R |
| Flash Memory | 32 MB |
| DDR Memory | 256 MB |
| Dimensions (L × W × H) | 442 × 260 × 44 mm |
| Weight | ＜5 kg |
HSGQ-XE08R 8 Port Epon OLT Interfaces
| Specification | Details |
|---|---|
| EPON Ports | 8 × EPON |
| GE Ports | 4 × 10/100/1000M RJ45 |
| Uplink Ports | 4 × 10G SFP+ |
HSGQ-XE08R 8 Port Epon OLT PON Specifications
| Specification | Details |
|---|---|
| Physical Interface | PON SFP Slots |
| Optical Module Type | 1000BASE-PX20+ / PX20++ / PX20+++ |
| Maximum Splitting Ratio | 1:64 |
HSGQ-XE08R 8 Port Epon OLT PON Functions
| Feature | Details |
|---|---|
| ONU Auto Registration | Supported |
| ONU Blacklist / Whitelist | Supported |
| DBA Configuration | Supported |
| P2P | Supported |
| ONU Authorization | Supported |
| ONU Auto Discovery | Supported |
| Automatic Loop-Back Test | Supported |
HSGQ-XE08R 8 Port Epon OLT Product Features
| Feature | Details |
|---|---|
| Wire-Speed Forwarding | Full Wire-Speed Forwarding Supported |
| MAC Address Table | 16K |
| Port Aggregation | Supported |
| Network Management | Complete Network Management Functions |
| QoS Standards | IP ToS, IEEE 802.1Q |
| DBA | Flexible DBA with Upstream & Downstream Traffic Speed Control |
| Traffic Control | Port-Based Traffic Control & Traffic Shaping |
| VLAN Features | VLAN Stacking, Trunk, Translation |
| IGMP Snooping | Supported |
| ACL / QoS | Supported |
HSGQ-XE08R 8 Port Epon OLT Layer 2 Functions
| Feature | Details |
|---|---|
| VLAN | Supported |
| VLAN Translation | Supported |
| QinQ | Supported |
| Maximum VLANs | 4094 |
| Port Mirroring | Supported |
| RSTP | Supported (Recovery Time ＜1s) |
| MSTP | Supported (Recovery Time ＜1s) |
| Link Aggregation | Supported (Recovery Time ＜10ms) |
| Storm Control | Supported |
| IGMP Snooping / Proxy | Supported |
| Port Isolation | Supported |
| ACL | Access Control Based on Data Flow |
| QoS | Based on Port, VID, ToS and MAC Address |
| PON Data Encryption | Supported |
HSGQ-XE08R 8 Port Epon OLT Layer 3 Functions
| Feature | Details |
|---|---|
| Static Routing | Supported |
| DHCP Server | Supported |
| DHCP Snooping | Supported |
| DHCP Relay | Supported |
| OSPF | Supported |
HSGQ-XE08R 8 Port Epon OLT Platform Management Features
| Feature | Details |
|---|---|
| Device List | Supported |
| Project Management | Supported |
| Version Release | Supported |
| License Management | Supported |
| Permission Management | Supported |
| User Management | Supported |
HSGQ-XE08R 8 Port Epon OLT Configuration & Management
| Feature | Details |
|---|---|
| Management Ports | Console Port, NMS Port |
| Management Methods | CLI, WEB, SNMP/NMS, CLOUD |
| Software & Firmware Upgrade | Supported |
| Command Prompt | Chinese / English |
| Ping & Debug Diagnostics | Supported |
| User Management | Supported |
| Log Management | Supported |
| Alarm Management | Supported |
HSGQ-XE08R 8 Port Epon OLT Environmental Conditions
| Parameter | Details |
|---|---|
| Operating Temperature | -10°C to 60°C |
| Storage Temperature | -40°C to 80°C |
| Storage Humidity | 5%–95% (Non-condensing) |
HSGQ-XE08R 8 Port Epon OLT Power
| Specification | Details |
|---|---|
| Power Supply | AC 100V–240V, 50/60Hz |
| Power Consumption | ＜40W |
HSGQ-XE08R 8 Port Epon OLT Supported Standards
| Standard | Details |
|---|---|
| EPON | IEEE 802.3ah EPON |
| Ethernet | IEEE 802.3 (10Base-T) |
| Fast Ethernet | IEEE 802.3u (100Base-TX) |
| Gigabit Ethernet (Fiber) | IEEE 802.3z (1000BASE-X) |
| Gigabit Ethernet (Copper) | IEEE 802.3ab (1000Base-T) |
| VLAN | IEEE 802.1Q |
