Description
The MikroTik RB260GSP is a compact 5-Port Gigabit PoE Smart switch built for small businesses, home labs, and SOHO environments that need to power connected devices directly through the network cable. It’s designed to simplify setup for small-scale deployments where both connectivity and power delivery matter.
At its core, the switch offers 5 Gigabit Ethernet ports alongside 1 SFP cage for fiber uplink flexibility. This combination allows businesses to connect and power PoE-capable devices such as IP cameras, wireless access points, and VoIP phones, while still having the option to extend the network over fiber.
One of the standout features of this switch is its passive PoE output on ports 2 through 5, which can power other PoE-capable devices using the same voltage applied to the unit itself, simplifying power delivery for small networks.
Driven by a high-performance Atheros QCA8337 switch chip, the MikroTik RB260GSP ensures efficient packet switching and bandwidth management across all its interfaces, keeping performance consistent even in busy small-office setups.
The switch is powered by SwOS, an operating system built specifically for MikroTik switch products. SwOS is fully configurable from a standard web browser, giving users all the basic functionality of a managed switch, plus more advanced controls.
Management flexibility is another area where the MikroTik RB260GSP performs well. It supports port-to-port forwarding, broadcast storm control, VLAN configuration, traffic mirroring, and bandwidth limitation, giving even small network setups genuine administrative control.
The switch also includes PCB temperature and voltage monitoring, giving administrators visibility into the device’s health directly through the SwOS interface for proactive maintenance and troubleshooting.
Built with a compact plastic case measuring just 113x139x28mm, the switch is genuinely unobtrusive, making it ideal for environments where desk or shelf space is limited but PoE power delivery still matters.
With passive PoE input across an 11 to 30V range and a maximum power consumption of 53W, the device comfortably powers multiple connected devices while remaining efficient for continuous small-office operation.
Whether the goal is powering a small fleet of IP cameras or setting up a compact home lab with PoE flexibility, this device offers a dependable balance of simplicity, power, and value.
Overall, the MikroTik RB260GSP stands out as a practical choice for small networks that want SwOS-powered PoE management in a compact package, all backed by the reliability of a proven brand.
MikroTik RB260GSP Specifications
| Specification | Details |
|---|---|
| Product Code | CSS106-1G-4P-1S |
| Switch Chip Model | QCA8337 |
| Dimensions | 113 × 139 × 28 mm |
| Operating System | MikroTik SwOS |
| Storage Size | 128 KB |
| Storage Type | FLASH |
| MTBF | Approximately 100,000 hours at 25°C |
| Tested Ambient Temperature | -20°C to 70°C |
MikroTik RB260GSP Powering
| Specification | Details |
|---|---|
| DC Inputs | 2 (DC Jack, PoE-IN) |
| DC Jack Input Voltage | 11–30 V |
| Maximum Power Consumption | 53 W |
| Maximum Power Consumption Without Attachments | 5 W |
| PoE Input | Passive PoE |
| Cooling Type | Passive |
| PoE Input Voltage | 11–30 V |
MikroTik RB260GSP PoE-Out
| Specification | Details |
|---|---|
| PoE-Out Ports | Ether2–Ether5 |
| PoE Out | Passive PoE |
| Low Voltage PoE-Out Current Limit | 1 A |
| Maximum Total Out Current | 2 A |
MikroTik RB260GSP Ethernet & Fiber
| Specification | Details |
|---|---|
| 10/100/1000 Ethernet Ports | 5 |
| SFP DDMI | Yes |
| SFP Ports | 1 |
MikroTik RB260GSP Monitoring & Certification
| Specification | Details |
|---|---|
| PCB Temperature Monitor | Yes |
| Voltage Monitor | Yes |
| Certification | CE, EAC, ROHS |
| IP Rating | IP20 |
MikroTik RB260GSP Included Parts
| Specification | Details |
|---|---|
| Power Adapter | 24V 2.5A Power Adapter |
| Power Cable | IEC Cord |
MikroTik RB260GSP Switching Performance
| Mode | Configuration | 1518 Byte | 512 Byte | 64 Byte |
|---|---|---|---|---|
| Switching | Non-blocking Layer 2 Throughput | 487.6 kpps / 5,922.0 Mbps | 1,409.8 kpps / 5,774.4 Mbps | 8,928.6 kpps / 4,571.4 Mbps |
| Switching | Non-blocking Layer 2 Capacity | 487.6 kpps / 11,844.0 Mbps | 1,409.8 kpps / 11,548.9 Mbps | 8,928.6 kpps / 9,142.9 Mbps |
| Switching | Non-blocking Layer 1 Throughput | 487.6 kpps / 6,000 Mbps | 1,409.8 kpps / 6,000 Mbps | 8,928.6 kpps / 6,000 Mbps |
| Switching | Non-blocking Layer 1 Capacity | 487.6 kpps / 12,000 Mbps | 1,409.8 kpps / 12,000 Mbps | 8,928.6 kpps / 12,000 Mbps |
