TP-Link TL-SL1311P is an 8-port desktop switch built for small offices and surveillance setups that need dedicated PoE+ power alongside flexible Gigabit uplink options. Combining full PoE+ support across all eight access ports with additional Gigabit and SFP connectivity, this switch offers a well-rounded solution for expanding wired networks that include powered devices.
At the core of the TP-Link TL-SL1311P are 8 individual 802.3af/at PoE+ 10/100Mbps ports, each capable of delivering up to 30W of power, alongside 2 additional Gigabit RJ45 ports and 1 Gigabit SFP slot for uplink flexibility. This gives the switch a total PoE budget of 65W across its eight PoE ports, comfortably supporting devices like IP cameras, wireless access points, and IP phones, all powered through the same Ethernet cable that carries data.
One of the practical advantages of the TP-Link TL-SL1311P is its Extend Mode, which increases PoE transmission distance from the standard 100 meters up to 250 meters. This trade-off, which reduces port speed while extended range is active, proves genuinely valuable for surveillance camera deployments spread across larger properties or outdoor perimeters where standard cable runs would otherwise fall short of reaching the desired coverage area.
Security and network organization are further supported through Isolation Mode, which allows one-click separation of client traffic across connected devices. This is particularly useful in surveillance or shared-office environments where individual devices shouldn’t be able to communicate directly with one another, adding a meaningful layer of protection without requiring complex configuration.
Reliability is reinforced through PoE Auto Recovery, which continuously monitors connected PoE-powered devices and automatically reboots any that become unresponsive or drop offline. This is especially valuable for unattended installations like remote security cameras, where physically resetting a device isn’t always convenient or immediately possible, helping keep critical systems online with minimal maintenance.
The switch’s three uplink options add genuine flexibility to network design. Uplink 1 is a Gigabit SFP slot suited for fiber connections over longer distances, while uplinks 2 and 3 are standard Gigabit RJ45 ports for typical copper connections. This combination allows the TP-Link TL-SL1311P to connect back to a core network switch or router using whichever medium best fits the installation, whether that’s fiber for longer runs or copper for standard office setups.
Setup is genuinely plug-and-play, requiring no software installation or manual configuration to begin operating. The completely fanless design ensures silent operation, making the switch well suited for noise-sensitive environments like offices, reception areas, or small equipment closets where a humming device would be noticeable and distracting.
For small businesses and property managers deploying surveillance systems or expanding networks with multiple powered devices, the TP-Link TL-SL1311P offers a dependable combination of solid PoE+ capacity, flexible uplink connectivity, and silent, reliable operation, making it a practical mid-tier choice for growing wired networks.
TP-Link TL-SL1311P Hardware Features
| Feature | Specification |
|---|---|
| Interface | • 8× 10/100 Mbps 802.3af/at PoE+ Ports, 2× Gigabit RJ45 Ports, 1× Gigabit SFP Port • AUTO Negotiation • AUTO MDI/MDIX |
| Network Media | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) |
| Fan Quantity | Fanless |
| Physical Security Lock | Yes |
| External Power Supply | External Power Adapter (Output: 53.5 VDC / 1.31 A) |
| Packet Forwarding Rate | 5.6544 Mpps |
| PoE Ports (RJ45) | • Standard: 802.3 af/at compliant • PoE Ports: Ports 1–8 • Power Supply: 65 W |
| Mac Address Table | 2K |
| Jumbo Frame | 16 KB |
| Switching Capacity | 7.6 Gbps |
| Dimensions ( W x D x H ) | 8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm) |
| Max. Power Consumption | • 5.61 W (220 V/50 Hz. no PD connected) • 77.32 W (110 V/50 Hz. with 65 W PD connected) |
| Max. Heat Dissipation | • 19.13 BTU/h (no PD connected) • 263.7 BTU/h (with 65 W PD connected) |
TP-Link TL-SL1311P Software Features
| Feature | Specification |
|---|---|
| Advanced Features | • Compatible With IEEE 802.3af/at Compliant PDs • Extend Mode Button (Ports 1–4 and Ports 1–8, Up to 250 m PoE power supply and data transmission) • Isolation Mode Button (Ports 1–8) • PoE Auto Recovery Button (Ports 1–8) • Mac Address Auto-Learning and Auto-Aging • IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure for Half-Duplex Mode |
| Transmission Method | Store-And-Forward |
Others
| Feature | Specification |
|---|---|
| Certification | FCC, CE, RoHS |
| Package Content | • TL-SL1311P • Power Adapter • Installation Guide |
| Environment | • Operating Temperature: 0–40 ℃ (32–104 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
