Description

Overview
Dimensions ⌀175.7 x 43.2 mm (⌀6.9 x 1.7″)
WiFi Standard WiFi 5
Spatial Streams 5
Coverage Area 185 m² (2,000 ft²)
Max. Client Count 250+
Uplink GbE
Mounting Ceiling, Wall (Lite Mount Included)
Power Method PoE

Performance
MIMO 5 GHz 2 x 2 (DL MU-MIMO)
2.4 GHz 3 x 3 (DL MU-MIMO)
Max. Data Rate 5 GHz 867 Mbps (BW80)
2.4 GHz 450 Mbps (BW40)
Antenna Gain
5 GHz 3 dBi
2.4 GHz 3 dBi
Max. TX Power
5 GHzc22 dBm
2.4 GHzc24 dBm
Max. BSSIDs 8 per Radio
Supported Data Rates
802.11ac (WiFi 5) 6.5 Mbps to 867 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80)
802.11n 6.5 Mbps to 450 Mbps (MCS0 – MCS23, HT 20/40)

Features
Wireless Meshing ✓
Band Steering ✓
802.11v BSS Transition Management ✓
802.11r Fast Roaming ✓
802.11k Radio Resource Management (RRM) ✓
Advanced Radio Management ✓
Passpoint (Hotspot 2.0) ✓

Captive Hotspot Portal
Custom Branding Landing Page ✓
Voucher Authentication ✓
Payment-Based Authentication ✓
External Portal Server Support ✓
Password Authentication ✓
Guest Network Isolation ✓
Private Pre-Shared Key (PPSK) ✓
WiFi Speed Limiting ✓
Client Device Isolation ✓
WiFi Schedules ✓
RADIUS over TLS (RadSec) ✓
Dynamic RADIUS-assigned VLAN ✓

Hardware
Max. Power Consumption 6.5W
Includes PoE Adapter ✓
Networking Interface (1) GbE RJ45 port
Weight Device: 240 g (8.5 oz) With mount: 315 g (11.1 oz)
Management Ethernet
Enclosure Material Polycarbonate
LEDs
System Status
Channel Bandwidth HT 20/40, VHT 20/40/80 (MHz)
NDAA Compliant ✓
Certifications CE, FCC, IC, Anatel: 01409-16-08356
Operating Frequency
US/CA:
2400 – 2472 MHz
U-NII-1: 5150 – 5250 MHz
U-NII-2A: 5250 – 5350 MHz
U-NII-2C: 5470 – 5725 MHz
U-NII-3: 5725 – 5850 MHz

Worldwide:
2400 – 2483.5 MHz
5150 – 5850 MHz
Ambient Operating Temperature
-10 to 70° C (14 to 158° F)
Ambient Operating Humidity
5 to 95% noncondensing

Software
Application Requirements
UniFi Network
Version 6.0.45 and later
