Description

The Ruijie Reyee RG-RAP62-Wall is a dual-band Wi-Fi 6 wall-plate access point built for commercial spaces that need strong gigabit wireless coverage along with flexible wired connectivity. It’s a practical choice for hotels, offices, and multi-room properties that want reliable performance combined with straightforward multi-device support.

Delivering Wi-Fi 6 AX3000 speeds, the Ruijie Reyee RG-RAP62-Wall reaches a maximum of 2401 Mbps in the 5 GHz band plus a maximum of 573 Mbps in the 2.4 GHz band, for a combined concurrent speed of up to 2974 Mbps. Dual-band 2×2 MU-MIMO keeps performance consistent even as multiple devices connect at once.

Wired connectivity is where this model stands out from its Lite counterpart. It includes 4 x 1GE LAN ports, with LAN4 supporting PoE Out, giving administrators the flexibility to power downstream devices like IP phones, cameras, or set-top boxes directly from the access point without extra cabling or adapters.

Physical design remains a priority despite the added ports. The unit features an ultra-thin profile with a thickness of just 23.5 mm, allowing it to sit discreetly on walls without disrupting the surrounding decor—well suited to hotel rooms and professional office environments alike.

Client capacity is handled through OFDMA and MU-MIMO technology, which together ensure stable access for up to 256 connected clients, making it a strong fit for busy corridors, meeting rooms, and shared workspaces.

Intelligence is built into daily operation through advanced AI-powered cloud features, including AI Roaming, AI Network Optimization, AI Heatmap Pro, and AI Diagnostics. These tools work automatically in the background to maintain strong, consistent performance without requiring constant manual adjustment.

Management is centralized through the Ruijie Cloud platform and the Ruijie Reyee App, both of which fully support rapid deployment of large-scale networks in minutes—ideal for properties managing multiple access points across various rooms or floors.

Deployment flexibility is enhanced further through Reyee Mesh support, allowing additional access points to be added easily as coverage needs grow, without extensive rewiring or added installation complexity.

Altogether, the Ruijie Reyee RG-RAP62-Wall combines true gigabit Wi-Fi 6 performance, versatile PoE-out wired ports, and intelligent AI-driven cloud management, making it a smart, scalable choice for businesses needing dependable wall-mounted wireless coverage.

RG-RAP62-Wall Product Information

Product Type	Wall AP

RG-RAP62-Wall Hardware Specifications

RG-RAP62-Wall Wi-Fi Radio

Radio design	Dual-radio4 spatial streams● 2.4 GHz: 2 x 2, MU-MIMO● 5 GHz: 2 x 2, MU-MIMO
Maximum wireless data rate	2974 Mbps
6 GHz wireless data rate	No
5 GHz wireless data rate	2401 Mbps
2.4 GHz wireless data rate	573 Mbps

RG-RAP62-Wall Antenna

Antenna	5 GHz: 1 built-in omnidirectional antennaIntegrated 2.4 GHz and 5 GHz: 2 built-in omnidirectional antennas

RG-RAP62-Wall Dimensions and Weight

Product dimensions (W x D x H)	86 mm x 23.5 mm x 125 mm (3.39 in. x 0.93 in. x 4.92 in.) (excluding the mounting bracket)
Color	White
Weight	≤ 0.33 kg (0.73 lbs.) (without packaging materials)

RG-RAP62-Wall Port Specifications

Number of 10/100/1000BASE-T ports	5

RG-RAP62-Wall Power Supply and Consumption

Power supply	PoE/PoE+
Local power supply	No
Dimensions of the DC connector	No
PoE budget	10 W (when power source is IEEE 802.3at-compliant)
Maximum power consumption	12 W (excluding PoE output)
